TREK - 2025 Marlin 5 Gen 3

Regular price: $1,099.00
Sale price: $899.00

Colour

Purple Flip To Trek Black Fade Matte Dnister Black

Size

Detail

Marlin 5 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail. It features a trail-savvy frame with a suspension fork, 9-speed Shimano CUES shifting and mounts for a rack and kickstand that make it an ideal choice for trail riders or anyone looking for a comfortable, stable commuter with the ruggedness of a real mountain bike.

Frame	Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Fork	SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 100 mm QR, 100 mm travel
Max compatible fork travel	120mm, XXS: 80mm
Hub front	Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub rear	Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer rear	173x5 mm QR
Rim	Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Spokes	14 g stainless steel, black
Tyres	Bontrager XT3 Comp, wire bead, 30 tpi
Max tyre size	Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer
Shifter	Shimano U4000, 9-speed
Rear derailleur	Shimano CUES U4000
Crank	Prowheel C10Y-NW, 30T steel narrow-wide ring
Bottom bracket	VP BC73, 73 mm, threaded cartridge
Cassette	Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain	Shimano LG500
Pedal	VP-536 nylon platform
Max. chainring size	1x: 34T, 2x: 36/22
Seatpost	Bontrager alloy, 31.6 mm, 12 mm offset
Handlebar	Bontrager alloy, 31.8 mm
Grips	Bontrager XR Trail Comp, nylon lock-on
Stem	Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree
Head set	Semi-integrated, 1-1/8"
Brake rotor	Tektro, 6-bolt, 160mm
Brake Set	Tektro HD-M275 hydraulic disc
Rotor size	Max brake rotor sizes - Frame: 180mm (XXS: 160mm), Fork: see fork manufacturer
Weight	M - 15.10 kg / 33.29 lbs (with tubes)
Weight limit	This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
